Macro Base Station and 5G Massive MIMO Base Station
GaAs MMIC DA
| Product Model | Frequency (GHz) | Gain (dB) | OP1dB （dBm） | OIP3 （dBm） | Operating Voltage / Current （V/mA） | Package Type |
| GSP702AQ | 2~4.2 | 36.5 | 27 | / | 5/110 | QFN |
GaN Power Transistor - Ceramic Package
| Product Model | Frequency (GHz) | Test Frequency Point (GHz) | Output Power (W) | Drain Efficiency (%) | Gain (dB) | Operating Voltage (V) | Match Type | Package Type |
| GLSD6P0002AL | DC-6.0 | 1.62 | 2 | 69 | 20.4 | 28 | Unmatched | Ceramic |
| GLSD6P0005AN | DC-6.0 | 4.4 | 5 | 47 | 13.6 | 28 | Pre-Matched | Ceramic |
| GLSD6P0015AL | DC-6.0 | 3.3 | 15 | 75 | 16 | 28 | Unmatched | Ceramic |
| GLSD6P0025BN | DC-6.0 | 2.45 | 26 | 80 | 18.2 | 28 | Unmatched | Ceramic |
| GLSA6P0040BT | DC-6.0 | 5.6 | 35 | 56 | 13.7 | 28 | Pre-Matched | Ceramic |
| GLSD6P0060AL | DC-6.0 | 0.3 | 59 | 58 | 20.8 | 28 | Unmatched | Ceramic |
| GHSD6P0100BT | DC~6.0 | 2.6 | 100 | 73 | 17.9 | 50 | Unmatched | Ceramic |
GaAs MMIC LNA
| Product Model | Frequency (GHz) | Gain (dB) | OP1dB (dBm) | NF （dB） | Operating Voltage / Current （V/mA） | Package Type |
| GSL805AD | 0.01~5 | 22 | 22 | 0.7 | 5/68 | DFN |
| GSL809AD | 0.5~6 | 22 | 22 | 0.7 | 5/70 | DFN |
| TC5985 | 5.9~8.5 | 15 | 14.9 | 1.14 | 5/16 | DFN |
